Overview/Description
PS7102 is a PCIe 5.0 Redriver IC with 8-channel amplification, up to 28dB equalization @16GHz, 70ps low latency, and configurable per-lane gain. It includes a two-pin voltage harness with MCIO SB power support, ensuring reliable, high-speed performance — and supports up to PCIe Gen6 applications.
Specifications
MCIO
• Pitch(mm): 0.6
• Number of Contacts : 74
• Gender: Plug End
• Termination Interface: Solder For Cable
• Current-Maximum per contact: 0.5A
• Voltage Rating: 30V DC per contact max
• Dielectric Withstanding Voltage: 300V DC
• Durability: 200 Cycles
• Plating Contact area: See Customer Drawing
• Temperature Range - Operating: -25°C to +65°C
Phison PS7102 8-Channel Redriver IC
• Low latency of 70 ps
• Body Size: 5.5 mm x 10 mm
Applications
Target Markets
