USB 3.0 Type B Male Connertor


Overview/Description

USB 3.0 Type B Male transmission speeds of up to 5 GBPS, the transmission speed of 3.0 A is 10 times as fast as USB2.0, downward compatible with USB2.0, USB1.1 device.
Products used in MP3, MP4, DC, DV, printers, scanners, flash drives, mobile hard disk, and main board and other devices. Comply with USB 3.0 _1. 0 version technical specification.

Specifications

Pitch(mm): 1.00
Number of Contacts : 9
Gender: Receptacle
Termination Interface: Surface Mount
Current-Maxinum per contact: 1.8A
Voltage Rating: 30V AC (RMS)/DC max
Dielectric Withstanding Voltage: 100V AC
Durability: 1500 Mating Cycles
Material Contact: Copper Alloy
Material Housing: High Temperature Thermoplastic (UL 94 V-O)
Plating Contact area: Au30μin
Plating solder area: 80μin/tin
Temperature Range - Operating: -30℃ to 85℃
